Laser Control / D4L
D4L - COMING SOON !
Compact, Stackable, All-in-One Current Source & Temperature Controller
FEATURES:
- Very low noise current generator
- Supports laser driving current up to 0.5A @ 8V
- High stability temperature-controlled laser operation
- 2 DC-coupled up to 2MHz inputs for modulating the laser
- Controlled with its embedded WEB-GUI or remotely over USB
- Powered via USB power delivery device ( included )
- Slim form factor: 110mm x 180mm x 30mm ( LxWxH )
- Can be used stand-alone or integrated into ppqSense D4L systems
FIND OUT WHAT D4L SYSTEM IS HERE !
Specifications
Laser grounding
AnodeGND
Max current ranges
0.5, 1, 1.5, 2 [A]
RMS current noise ( 10Hz – 1MHz )
<1 μA RMS
Curret noise spectral density
<400 pA/√Hz
Current stability ( 1h )
10 ppm FS
Compliance voltage
18V
Analog modulation channels
2
Frequency range
DC – 2 MHz (-3 dB)
Gain
10 mA/V, 500μA/V
Max input signal
±10V
Digital modulation channels (optional)
2
Frequency range
250 mHz – 2 MHz (-3 dB)
Max current
±75 mA, ±2.5 mA
Laser grounding
AnodeGND, CathodeGND
Max current ranges
0.5, 1, 1.5, 2 [A]
RMS current noise ( 10Hz – 1MHz )
<1 μA RMS
Current noise spectral density
<400 pA/√Hz
Current stability ( 1h )
10 ppm FS
Compliance voltage
18V
Analog modulation channels
Number
2
Frequency range
DC – 2 MHz ( -3dB )
Gain
10 mA/V, 500 uA/V
Max input signal
±10 V
Digital modulation channels (optional)
Number
2
Frequency range
250 mHz – 2 MHz ( -3dB )
Max current
±75 mA, ±2.5 mA
