QubeCL

High performances, Modular System for QCL Lasers

QubeCL is a modular platform that provides all the tools for driving and controlling quantum cascade lasers (QCLs) at unprecedented levels of precision and simplicity.

QCLs are among the most resource-demanding devices, in terms of voltage compliance, maximum current ratings, current noise and temperature stability.

Select your QubeCL configuration and contact us for a quotation.

Specifications

Laser grounding

AnodeGND

Max current ranges

0.5, 1, 1.5, 2 [A]

RMS current noise ( 10Hz – 1MHz )

<1 μA RMS

Curret noise spectral density

<400 pA/√Hz

 Current stability ( 1h )

10 ppm FS

Compliance voltage

18V

Analog modulation channels

2

Frequency range

DC – 2 MHz (-3 dB)

Gain

10 mA/V, 500μA/V

Max input signal

±10V

Digital modulation  channels (optional)

2

Frequency range

250 mHz – 2 MHz (-3 dB)

Max current

±75 mA, ±2.5 mA

Laser grounding

AnodeGND, CathodeGND

Max current ranges

0.5, 1, 1.5, 2 [A]

RMS current noise ( 10Hz – 1MHz )

<1 μA RMS

Current noise spectral density

<400 pA/√Hz

Current stability ( 1h )

10 ppm FS

Compliance voltage

18V

Analog modulation channels

Number

2

Frequency range

DC – 2 MHz ( -3dB )

Gain

10 mA/V, 500 uA/V

Max input signal

±10 V

Digital modulation channels (optional)

Number

2

Frequency range

250 mHz – 2 MHz ( -3dB )

Max current

±75 mA, ±2.5 mA

Get a quote

How to order a QubeCL :

  1. Compose the code by choosing the modules you need.
  2. Insert the code in the contact form together with your request, you will receive a quote very quickly.

Connect the laser

Optional for QubeCL only, we have developed the HHL laser shield board that allows you to connect your laser in HHL package to the QubeCL.

If you wish to have an HHL laser shield board, please indicate this in your order.
